Narrowboat Hull & Superstructure Specification:
Steelwork 10-6-5-4
100x65x7 angle to floor
60x60x6 angle to hull sides
25x25x3 box to cabin sides
25x25x3 box to cabin roof
All hull plates welded both sides
12ft swim standard
4x rubbing strakes to bows
1x rubbing strake full length, under water line
Centre mooring ring to cabin
Scroll work to bow & stern deck cants


T-bar cabin handrail; scroll work ends
Integral fuel tank with, feed & return pipework, vent, drain & tested
Self draining forward & and rear decks
Forward T stud & rear dollies
Engine beds to suit
Keel cooling tank with baffles
Steel rear doors with sliding hatch
Solid rudder & swans neck bar
Window apertures cut to size
Heavy duty dropped skeg
Quick release weed hatch
Quality S275 43A Steel plate sections services
